POWER: | 25 WCW |
| FREQUENCY: | 225 to 400 MHz |
|
| ISOLATION (MIN.): | 18.0 dB |
|
| INS. LOSS (MAX.): | 0.7 dB |
|
| VSWR (MAX): | 1.35:1 |
|
| CONNECTORS: | SMA FEMALE |
|
| SIZE: | 2.56" x 2.05"
x 1.14" |
|
| OPERATING TEMPERATURE: | 0ºC to +48ºC |
Note:
If you are intrested in purchasing an existing model, upon ordering, you will be issued a new model number with Serial numbers starting at 101.
