POWER: | 200 WCW |
| FREQUENCY: | 225 to 400 MHz |
|
| ISOLATION (MIN.): | 15.0 dB |
|
| INS. LOSS (MAX.): | 0.8 dB |
|
| VSWR (MAX): | 1.45:1 |
|
| CONNECTORS: | TNC (3) FEMALE |
|
| SIZE: | 2" x 2" x .75"
|
|
| OPERATING TEMPERATURE: | -20ºC to
+55ºC |
Note:
If you are intrested in purchasing an existing model, upon ordering, you will be issued a new model number with Serial numbers starting at 101.
