POWER: | 40 WATTS |
| FREQUENCY: | 221 to 404 MHz |
|
| ISOLATION (MIN.): | 14.0 dB |
|
| INS. LOSS (MAX.): | 0.8 dB |
|
| VSWR (MAX): | 1.35:1 |
|
| CONNECTORS: | SMA (3) FEMALE |
|
| SIZE: | 2.05" x 2.56"
x 1.14" |
|
| OPERATING TEMPERATURE: | -40ºC
to +85ºC |
|
| WEIGHT: | 12.5 OZ. |
Note:
If you are intrested in purchasing an existing model, upon ordering, you will be issued a new model number with Serial numbers starting at 101.
